All parts in your Toto toilet serve a specific function. For instance, the flush valve inside the tank controls the release of water into the toilet bowl during a flush. So, what happens if it malfunctions? This Toto flush valve troubleshooting guide will help solve this issue.
Common Toto flush valve issues include a weak flush, continuous running, and sticking flush valve. Other problems are the flush valve turning off and on without flushing, excessively high or low flow rate, and the flush valve not flushing.
Troubleshooting these issues is important because they can have multiple causes. Therefore, let’s tackle each problem.
Toto Flush Valve Troubleshooting (Causes & Fixes!)
| Problem | Probable Causes | Recommended Fixes | |
| 1. | Flush Valve Not Flushing | Water supply issue Clogged flush valve or toilet trap Faulty flush valve seal Blocked or faulty fill valve Malfunctioning flush handle or lever | Turn on the shut-off valve Unclog your toilet Replace the flush valve seal Clean or replace the fill valve Tighten or replace the flush handle |
| 2. | Weak Flush | Low water level Partially closed water supply valve Clogged rim holes or jet openings Malfunctioning flush valve or flapper Partially blocked or obstructed trapway | Adjust the fill valve or float mechanism Turn on the valve Remove obstructions Replace the flush valve Remove blockages with a plunger or auger |
| 3. | Continuous Running | Worn-out flapper Excessively tight chain Damaged flush valve seal High water level Malfunctioning fill valve Leaking components or connections | Clean or replace the flapper Adjust the chain Replace the seal Adjust the fill valve or float mechanism Clean or replace the fill valve Tighten or replace faulty parts |
| 4. | Sticking Flush Lever | Obstructions or debris Friction Misaligned lever Wrong chain length Damaged flush lever | Clean the obstructions Lubricate the moving parts Realign the lever Adjust the chain Install a new flush lever |
| 5. | Flush Valve Turning Off and On Without Flushing | Worn-out flush valve seal Tight chain High water level | Clean or replace the flush valve seal Loosen the chain Adjust the water level |
| 6. | High Flow Rate | Damaged flush valve seal high water level Faulty flush valve | Fit in a new flush valve seal Adjust the fill valve or float mechanism Replace the flush valve |
| 7. | Low Flow Rate | Partially closed water supply valve Obstructed water supply line Malfunctioning fill valve Low water level | Turn on the valve Clean the supply line Replace or clean the fill valve Adjust the water level |
1. Flush Valve Not Flushing
If your Toto flush valve stops flushing, look into the following causes to see which is causing the problem.
a. Water Supply Issue
Check if there is sufficient water supply to the toilet. If the water shut-off valve is closed or malfunctioning, it can restrict water flow and prevent proper flushing.
b. Clogged Flush Valve Or Toilet Trap
A clog in the flush valve or the toilet trap can prevent water from flowing and cause flushing problems.
c. Faulty Flush Valve Seal
Your flush valve seal could be worn out, damaged, or not seated properly, preventing water from entering the bowl for flushing. Inspect the flush valve seal for any signs of damage or deterioration.
d. Issues With The Fill Valve
If the fill valve is not functioning correctly, it might not allow enough water to fill the tank after flushing, resulting in a weak flush. Check the fill valve for any blockages or malfunctions.
e. Malfunctioning Flush Handle Or Lever
The flush handle or lever might be loose, disconnected, or not engaging the flush valve properly. So, ensure the handle is fastened to the flush valve mechanism.
Fix
- Turn the valve fully counterclockwise to ensure it is open.
- Eliminate clogs using a plunger or a toilet auger; in more severe cases, call a professional plumber to clear the blockage.
- Replace your Toto flush valve.
- Clean the fill valve to remove any blockages or replace it.
- Tighten or replace the flush handle if it’s loose or damaged.
2. Weak Flush
So, your Toto toilet flushes, but it has a weak flush. What could be causing this? Here are the probable causes and solutions.
i) Low Water Level In The Tank
To get a strong flush, the water inside your Toto toilet tank should be at the recommended level, usually marked on the inside or specified in the user manual. If the level of water is too low, the toilet will deliver a weak flush.
ii) Partially Closed Water Supply Valve
If the water supply valve is partially closed, it can restrict water flow, resulting in a weak flush.
iii) Clogged Rim Holes Or Jet Openings
Over time, mineral deposits, sediment, or debris can accumulate in the rim holes or jet openings around the bowl’s inner edge. This can obstruct the flow of water and lead to a weak flush.
iv) Malfunctioning Flush Valve
A worn-out or malfunctioning flush valve can restrict the water flow and result in a weak flush. Inspect the flush valve for any signs of damage or deterioration.
v) Partially Blocked Or Obstructed Trapway
Objects or accumulated debris can partially block or obstruct the trapway, restricting water flow and, in turn, causing a weak flush. In such cases, using a toilet auger or calling a professional plumber to clear the blockage can help restore proper flushing.
Fix
- Adjust the fill valve or float mechanism to increase it.
- Open the valve by turning it counterclockwise and allow water to flow fully.
- Use a wire hanger or a small brush to clean these openings and remove any obstructions.
- Replace the flush valve.
- Clear the blockage on the trapway using a plunger or plumber’s snake.
3. Continuous Running
A continuously running Toto flush valve indicates an issue with the flushing mechanism. Take these steps to troubleshoot and resolve the problem.
a) Worn Out Flapper
A worn-out flapper might not seal well, causing a continuous water leak into the toilet bowl. Inspect the flapper for any signs of deterioration or misalignment.
b) Adjust The Chain
The chain should have the right amount of slack. If it is too tight, it can prevent the flapper from closing completely, resulting in a continuous flow of water.
c) Check The Flush Valve Seal
The flush valve seal ensures a watertight seal when the toilet is not in use. If the seal is worn out or damaged, it can cause water to leak into the bowl continuously.
d) High water level
Setting the water level too high causes it to flow continuously into the overflow tube, making the toilet run.
e) Check The Fill Valve
Your toilet will also keep running if the fill valve is not functioning properly. If you suspect that it could be the cause of your continuously running toilet, inspect the fill valve for any blockages or malfunctions.
f) Look For Leaks
Inspect the various connections and components of the toilet, including the fill valve, flush valve, and supply line, for any signs of leaks because a leak can cause the toilet to run continuously.
Fix
- Clean or replace the flapper.
- Adjust the chain to ensure enough slack, allowing the flapper to close fully after flushing.
- Inspect the seal and replace the flush valve seal.
- Adjust the fill valve or float mechanism to lower the water level.
- Clean or replace the fill valve.
- Tighten or replace any faulty parts.
4. Stuck Flush Lever
Sometimes, the flush lever feels stuck or doesn’t return to its original position after flushing due to various reasons. For instance, the flush lever may be sticking due to obstructions or debris around the lever mechanism.
Also, friction can prevent the lever from moving more smoothly. In addition, it can get stuck because it is not aligned correctly with the flush valve.
Another reason for this issue is an excessively long or short chain, thus interfering with the proper lever operation. Perhaps you have a damaged flush valve lever.
Fix
- Clean the flush valve lever.
- Apply a small amount of lubricant, such as silicone spray or plumber’s grease, to the flush lever and its moving parts. However, be cautious not to apply excessive lubricant, as it can attract debris and cause further issues.
- Loosen the nut on the back of the flush lever and reposition it, ensuring it aligns properly with the flush valve, then tighten it securely.
- Adjust the chain length by reattaching it to a different link on the chain, ensuring there is enough slack for the lever to move freely.
- Replace the flush valve lever. 2PCS Toilet Tank Flush Lever Replacement (View on Amazon) is Compatible with TOTO THU068#CP Trip Lever For St743S, St454E.
5. Flush Valve Turning Off and On Without Flushing
The flushing mechanism is also the culprit if your Toto flush valve turns on and off without flushing. If the flush valve seal doesn’t seal properly, it can make water leak into the bowl triggering the flush valve to turn off and on intermittently. An excessively tight chain can also cause intermittent flushing by keeping the flush valve from closing correctly.
Furthermore, the flush lever mechanism, including the lever arm and the lift chain, could be sticking or binding, causing the flush valve to turn off and on unexpectedly. Setting the water level too high also causes this problem.
Fix
- Clean or replace the flush valve seal.
- Adjust the chain.
- Clean or adjust the mechanism to ensure smooth operation.
- Adjust the water level.
6. High Flow Rate
A damaged flush valve seal, setting the water level too high, or a faulty flush valve or one not closing properly can lead to a high flow rate.
Fix
- Replace the flush valve seal.
- Adjust the fill valve or float mechanism to lower the water level.
- Replace the flush valve. Toilet Flush Valves 2-Inch Dual Flush Valve Replacement Kit (View on Amazon) is compatible with TOTO THU435 THU224 Flush Valve.
7. Low Flow Rate
A partially closed water supply valve, obstructed water supply line, malfunctioning fill valve, or low water level causes this issue.
Fix
- Turn the valve counterclockwise to open it fully.
- Clean the supply line.
- Clean or replace the fill valve.
- Adjust the water level.
Final Remarks on Toto Flush Valve Troubleshooting
Refer to this post for guidance when you experience issues with your Toto flush valve. It contains the causes and fixes for the various problems.
